Description
RIOT13000 – A STEP FURTHER
The RIOT expands with this heavyweight. Based on the same fullbridge tech as the RIOT 7500, but with twice the performance. Rated at 11000 watts and with >145 volt output, this bad boy packs a punch equivalent to a TKO.
GOT CURRENT
With this much power comes the responsibility of having the current to back it up. Don’t cheapen on your electrical and buy the biggest amp you can to save some money. In the long run it is a catastrophe waiting to happen. Plan adequately before entering the big boy league of amps.
The 900 A fuse rating might have you fooled, but the RIOT13000 has a higher efficiency circuit vs traditional half bridge designs. At peaks the amp can easily exceed the fuse rating by 30%, so I guess it makes sense having more batteries than you initially planned for?
The amplifier is still compact, a mere footprint of 24.4″ x 8.85″ / (62 x 22.5 cm) makes the amplifier fit in most installs today. To increase the surface area of the heatsink, the RIOT 13000 has fins on the top, slightly deviating from the sleek heatsink of the M and Zero series. In addition there’s multiple high speed fans positioned in a suck and blow mode to help keep things cool when your voice coils aren’t!
Even though it should be common knowledge by now, the fullbridge amps are not strap able. Basically because they are already bridged internally.
13.8V <1% THD | 14.4V <1% THD | ||
---|---|---|---|
Power @ 4 Ω: | 1 x 2800 w | 1 x 2950 w | |
Power @ 2 Ω: | 1 x 5400 w | 1 x 5500 w | |
Power @ 1 Ω: | 1 x 10000 w | 1 x 11000 w |
Frequency Response: | 10 Hz ~ 20 KHz (+/- 1 dB) |
Input Sensitivity: | 5 ~ 0.2 V |
Crossover: | 24 dB / Oct |
Low Pass Crossover 24 dB / Oct: | 50 Hz ~ 20 KHz |
High Pass Crossover 12 dB / Oct: | 10 Hz ~ 2 KHz |
Bass Boost: | 0 ~ 12 dB |
Bass Boost Frequency: | 35 Hz ~ 70 Hz |
Damping Factor: | 200< |
Power Terminal gauge: | 0 GA x 2 |
Fuse Rating: | 900 A |
Operational voltage: | 9 V ~ 16 V |
Dimensions: | 420 x 217 x 61 MM |
