Description
Gladen RC 1200c1 – Mono Digital Amplifier
Gladen Audio’s new RC line of amplifiers is a simple series that includes Class AB stereo amps, along with Class D mono amps. All amps use dual layer printed circuit boards, surface mount devices, flexible crossovers, and high level input with auto sensing circuit. Each mono amp allows the use of an optional sub level control to be used in adjusting output. The RC line boasts a small footprint, and utilizes the highest quality parts in order to ensure absolute reliability.
• Input with low- or high-level signal
• High-level with autosense function (no remote signal required)
•Low Pass Filter from 40 to 220 Hz
•Subsonic Filter from 10 to 50 Hz
• Bass Boost Level: -6dB, 0dB or +6dB
• Wired Remote controller RTC-2 (optional )
• Protection for overheating, overloading, short circuitry and speaker DC protection
• Massive heavy aluminum-heat sink
Technical Specifications | |
---|---|
Power @ 4 Ω: | 1 x 400 w |
Power @ 2 Ω: | 1 x 650 w |
Power @ 1 Ω: | 1 x 1120 w |
Frequency Response: | 20 Hz ~ 220 Hz (+/- 2 dB) |
Signal to Noise Ratio: | > 100 dB |
Input Sensitivity: | 10 ~ 0.2 V |
Crossover: | 24 dB / Oct |
Low Pass Crossover: | 45 Hz ~ 220 Hz |
Subsonic Filter: | 10 Hz ~ 50 Hz |
Damping Factor: | >80 |
Power Terminal Gauge: | 4 GA x1 |
Fuse Rating: | 80 A |
Operational voltage: | 10 V ~ 16 V |
Dimensions: | 295 x 150 x 50 MM |
